2D Semiconductor Materials
2D materials can broadly be grouped by their properties and potential applications. They are materials which consist of atomically thin layers that are weakly bonded to one another by van de Waals forces.
Our collection offers high quality, low cost 2D materials in crystal, powder, or film form.
Browse 2D Materials
Explore the unique properties of black phosphorus in crystal or powder forms.
Browse our MoS2 powders, single crystals, and films.
For high purity graphene materials, take a look at our varied collection.
One of the most studied 2D materials.
Key Features and Applications
- From 2D semiconductors in optoelectronics and nanotechnology to flexible electrodes, energy storage and anti-corrosion coatings, our 2D materials – including graphene and molybdenum disulfide – offer a broad range of applications.
- Explore potential uses in groundbreaking biomedical applications such as tissue engineering, sensors, and drug deliveries, as well as advanced aerospace applications.
- Graphene and its derivatives not only boast extraordinary properties but also come at a relatively low cost, opening new avenues for novel functionalities and product enhancement.
- Dive into the world of magnetic 2D materials, like the highly studied iron phosphorus trisulfide, often referred to as 'magnetic graphene'.
More on 2D Materials
Interest in 2D materials has increased dramatically since the successful mechanical exfoliation of graphene in 2004 by Novoselov and Geim.
2D materials can be created from a bulk material via several different methods, the simplest of which is mechanical exfoliation. Also known as the Scotch-tape method, the weak weakly van der Waals forces that bond the single-atom-thick layers in the material together can be overcome with a piece of sticky tape. More sophisticated methods like chemical vapour deposition can be used for larger and more uniform 2D flakes.
