Amber Syringe Compatible with the Ossila Spray Coater
Amber colour protecting light-sensitive/UV curing coatings
Specifications | Gallery | In the Box
The syringe barrel is made from low friction polypropylene, silicone and chloride free (non-sterile). Its amber colour protects light-sensitive/UV curing coatings from premature curing. It features a double helix luer lock for attachment of the PTFE tubing (supplied with female luer connection) which provides a secure, leak free connection to the Spray Coater fluid line or nozzle.
Specifications
Amber Syringe
| Syringe Material | Polypropylene |
|---|---|
| Capacity | 10cc (10ml) |
| Length | 3.58" - 90.93mm |
| Outer Diameter | 0.72" - 18.36mm |
| Inner Diameter | 0.62" - 15.72mm |
| Maximum Operating Pressure | 100 psi (6.9bar) |
| Material | Stainless steel 316 |
| Colour | Amber |
Amber Syringe Top
| Syringe Adapter Material | Polypropylene |
|---|---|
| Colour | Yellow |
Syringe Adapter & Tubing
| Tubing Material | PTFE |
|---|---|
| Tubing Length | 410mm |
| Outer Diameter | 4mm |
| Inner Diameter | 3.2mm |
| Connector type | Female Luer Lock |
| Connector Material | Polypropylene |
Amber Syringe Gallery
In the Box
- Amber Syringe
- Syringe Adapter
- PTFE Tubing
