Welcome to Ossila. We specialize in the supply of components and materials for rapid prototyping of thin film and organic electronics including:

  • Photovoltaics (PVs/ OPVs)
  • Organic & polymer light emitting diodes (OLEDs/PLEDs)
  • Organic and thin film field effect transistors (OFETs/FETs)
  • Perovskite-based solar cells


  Products

line
OLED and OPV Components perovskite photovoltaic Specialist Consumables - syringe filter
Product Catalogue Perovskites Test Equipment


  Support

line
OPV and OLED overview Support videos OFET overview
System Overviews Fabrication Guides Useful Tools


We aim to offer the best possible support and advice for our products and therefore provide as much information as we can to make them easy to use.

As an example, click below to see our fabrication video detailing how to produce and measure perovskite-based solar cells using our materials, inks, substrate systems and test equipment. The same components and techniques can be used to produce a range of organic and thin film devices; you can find similar videos for other device types on our Fabrication Guides page.

perovskite photovoltaic fabrication video

Ossila was founded to provide the equipment, consumables and services to accelerate organic and thin film research.

Whether you're looking for polymers for organic photovoltaics, patterned substrates for thin film LEDs, inks for perovskite solar cells or shadow masks for thin film FETs, we provide a complete package to enable your research. Our range of specialist materials, including PCBM, PCDTBT, PEDOT:PSS, are sourced from world leading manufacturers or produced in house to the highest quality.

We also offer high quality test and measurement equipment to enable rapid and efficient testing of your thin film devices. Our range includes affordable plug-and-play test boards, fully integrated FET testing systems and software, and even equipment for processing thin film devices such as our vacuum-free spin coater. If you have a glovebox and evaporator then Ossila becomes a one-stop shop to produce and test efficient thin film electronics.

Ossila can also help to speed up discovery by providing a full design, processing, fabrication and testing service for new organic and inorganic materials, all in complete confidence, which can help you to accelerate your materials development programme. We also offer training workshops for PV/LED or FET fabrication to help you improve your knowledge or refresh your skills.
